Overview
The **Lycoming Cylinder Assembly (P/N 1949334)** is a fundamental component of the Lycoming IO-720 series aircraft engines, forming the combustion chamber where fuel and air are ignited to produce power. As a critical part of the reciprocating engine's power section, this assembly directly houses the piston, intake and exhaust valves, and spark plugs, facilitating the four-stroke cycle. Its integrity is paramount for engine performance, efficiency, and safety.Specifications
- Type: Air-cooled, horizontally opposed engine cylinder assembly.
- Material: Forged steel barrel, typically nitrided for wear resistance, mated to a cast aluminum alloy cylinder head.
- Bore Diameter: Specific to Lycoming IO-720 engine series (standard bore for the 720 cubic inch displacement).
- Stroke: Designed to accommodate the IO-720 piston stroke.
- Valve Configuration: Includes two intake and two exhaust valves, guides, and seats within the cylinder head.
- Spark Plug Bosses: Two threaded bosses for spark plug installation per cylinder, typically 18mm.
- Mounting: Features a robust flange for secure attachment to the engine crank
- Stock: Out of Stock - On Backorder
- Manufacturer Part #: 1949334
- Part#: 1949334
