Overview
The Instrument Panel Structural Component (P/N 63464-05) serves as a critical, non-flight-critical support element within the cockpit of various Piper PA-32 series aircraft. This part is integral to the overall integrity and layout of the instrument panel, providing foundational support and mounting points for various instruments, avionics, and control systems. It plays a crucial role in maintaining the structural rigidity of the flight deck, ensuring that essential pilot instruments are securely positioned and protected from vibration and operational stresses during flight.Specifications
While precise engineering drawings and material specifications for P/N 63464-05 are typically found in manufacturer-specific maintenance manuals, its design adheres to the rigorous standards required for aircraft structural components. As a part of the instrument panel, it is engineered to withstand operational vibrations and environmental conditions common in general aviation aircraft.- Material: Typically constructed from aircraft-grade aluminum alloy or a similar lightweight, high-strength composite, selected for its durability and resistance to fatigue and corrosion in an aviation environment.
- Finish: Often features a protective primer or a matte black finish to minimize glare and resist minor abrasions, consistent with interior cockpit components.
- Weight: Specific weight data is not generally published for individual structural panel components but is precisely factored into the aircraft's weight and balance calculations.
- Dimensions: Designed to fit specific contours and attachment points within the PA-32 series instrument panel framework, ensuring precise alignment with surrounding structures and instrument cutouts.
- Electrical Specifications: This is a passive structural component and does not posses
- Stock: Out of Stock
- Manufacturer Part #: 63464-05
- Part#: 63464-05
