The Fillister-Head Machine Screw, identified as part number AN509-10R4, is a fundamental piece of hardware utilized across various systems within the Beech T-34 Mentor aircraft. This specific screw belongs to the broad category of standard AN (Air Force-Navy) hardware, signifying its adherence to stringent military specifications for aviation use. Its primary role involves securing components where a robust, compact head is desirable, such as attaching access panels, fairings, interior trim, instrument mounts, or other non-structural and lightly structural assemblies throughout the airframe.
Specifications
- Part Number: AN509-10R4
- Standard: AN509 Series (Fillister Head Machine Screw)
- Material: Corrosion Resistant Steel (CRES), also known as Stainless Steel. This provides excellent resistance to corrosion, a critical factor in aviation environments.
- Head Type: Fillister Head, characterized by a cylindrical shape with a flat top, offering a clean, low-profile finish and strong driving characteristics.
- Drive Type: Typically slotted drive, designed for standard flat-blade screwdrivers.
- Stock: Out of Stock - On Backorder
- Manufacturer Part #: AN509-10R4
- Part#: AN509-10R4
